Tektronix MSO-DPO 4000 Series Automated Verification Software

Description

Tektronix DPO-MSO 4000 Series Automated Verification Software

🏆 Reduce downtime: ~1.5 hours automated vs ❌ 4+ hours manual testing.

Streamline your oscilloscope calibration process with our Tektronix DPO-MSO 4000 Series Automated Verification Software. Designed to support all models in the Tektronix 4000 Series, this powerful solution automates performance verification and helps you ensure compliance with manufacturer specifications—quickly and reliably. *Internet required to run.

Compatible with leading calibrators including the Fluke 5522A, 5520A, 5502A, and 5560A, this software is ideal for metrology labs seeking accuracy, repeatability, and reduced testing time.

✅ Supports Tektronix DPO4000 and MSO4000 Series oscilloscopes: DPO4032, MSO4032, DPO4104, DPO4054, DPO4034, MSO4104, MSO4054 and MSO4034.
✅ Works with Fluke 5522A, 5520A, 5502A, and the newer 5540A, 5550A, 5560A calibrators equipped with the relevant scope options.
✅ Automated test sequences aligned with manufacturer specs according to the Fluke calibrator capabilities.
✅ Reduces manual error and increases calibration throughput.
✅ No high-cost license fees – Just 25 PayPerCal credits per test run per asset/serial number. Trial runs included!
✅ Lifetime license available for offline use and customization – Ask us for a quote!

Perfect for labs with diverse Tektronix equipment, this software improves efficiency while maintaining high-quality calibration standards.

🔧 Requirements:

• Internet connection

• USB cable for Tektronix DPO or MSO 4000 Series oscilloscope + NI USB-GPIB adapter for Fluke calibrator standard

• NI VISA drivers + NI 488.2 drivers – Click to download NI VISA here and NI 488.2 here

• Microsoft Excel

• Windows laptop or desktop

• 50 ohm BNC cable

• 50 ohm BNC Feed through Terminator

🧪 Minimum Standard Equipment:

• Fluke 5522A, 5520A, 5502A, and the newer 5560A calibrators with *Scope option.  SC1100 recommended to cover all 4000 Series Oscilloscopes.

📄See our instructions Connecting Interface Cables to properly connect devices together.

* This procedure is based on the Tektronix DPO-MSO 4000 Series Specification and Performance Verification Technical Reference, Revision B.

For manufacturer description from Tektronix, click here.

🔐 Lifetime license option available — includes test and standard customization. Contact us 📧 via email here for a quote.

¹ Domini Technologies makes no representation that this procedure is complete. By purchasing a non-exclusive license, you agree to the Terms of Use. For more information, contact us 📧 via email here.
